| Marco | Series 1 6061 Aluminum, 27.5”/29" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, Chainstay Mounted Disc Brakes |
| Suspensión delantera | SR Suntour XCE Disc, 100mm Travel, Preload Adjustment, 46mm Offset |
| LLantas | Marin, Double Wall Alloy |
| Maza trasera | Forged Alloy, 6-Bolt Disc, 32H |
| Maza delantera | Forged Alloy, 6-Bolt Disc, 32H |
| Rayos | 14g Black Stainless Steel |
| Neumáticos | MTB, 27.5/29x2.25" |
| Desviador trasero | Shimano Tourney, 7-Speed |
| Desviador delantero | Shimano FD-TX500 |
| Palanca de cambios | Shimano Tourney 3x7-Speed |
| Volante | Alloy Crank, Steel Chainrings, 42/34/24T |
| Motor | Sealed Cartridge Bearings, Square Taper |
| Cadena | KMC Z8 |
| Piñon | SunRace 7-Speed, 11-34T |
| Frenos delanteros | Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor |
| Frenos traseros | Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor |
| Manilla de freno | Shimano w/ Integrated Shifters |
| Manubrio | Marin 31.8 Riser, 12mm Rise, 780mm Width |
| Tee | Marin Alloy, 31.8mm, 45mm |
| Puños | Marin MTB, Closed End |
| Dirección | FSA No.10-P |
| Tubo de asiento | Marin Alloy, 27.2mm |
| Asiento | Marin MTB |
| Asiento | Nylon Platform |
